Item

Specification

Item

Specification

Frequency Range SAT

5-860 (MHz)

Output Level ANT

105 (dBuV)

Frequency Range ANT

950-2150 (MHz)

Output Level SAT

110 (dBuV)

Gain SAT

20 (dB)

Noise Figure

6 (dB)

Gain ANT

18 (dB)

DC Power Consumption

350 (mA)

Slope Control SAT

0 / 6 (dB) selectable

Supply Voltage (VDC)

20V (±1) 2000mA

Slope Control ANT

0-10 (dB)

Temperature Range

-20℃ - 60℃

Return Loss

10 (dB)

Impedance (all ports)

75 (Ω)

Gain Adjustable Range

0-10 (dB)

Inputs

16 SAT+1 Terr.

interface

F connectors

Outputs

16 SAT+1 Terr.
